Name: Polcd Small 2.8 inch 240x320 QVGA High Brightness 300nits MCU RGB interface IPS TFT display
Brand: Shenzhen P&O Technology Co., Ltd
SKU: P028B122-IPS
Availability: InStock

Huis > producten > Kleine TFT-Vertoning >

Polcd Small 2.8 inch 240x320 QVGA High Brightness 300nits MCU RGB interface IPS TFT display

2.8 inch QVGA TFT display

high brightness 300nits IPS display

MCU RGB interface TFT screen

Plaats van herkomst:

Shenzhen, China

Merknaam:

Polcd

Certificering:

RoHS, ISO9001

Modelnummer:

P028B122-IPS

Contacteer ons

Verzoek om een Citaat

Productdetails

Aantal pixel:

240RGB(H)x320(V)

Schermgrootte:

2,8 inch

Weergavegebied:

43.20(H)x57.60(V)

Helderheid (CD/m²):

300

Interface:

MCU 8/16bit

Bestuurder IC:

ST7789V

Betaling & het Verschepen Termijnen

Min. bestelaantal

1 stuk

Prijs

Please contact us for latest price

Verpakking Details

FCL-grootte: 40*30*20cm/Steekproef die verpakken: 20*18*13cm

Levertijd

1-7 werkdagen

Betalingscondities

T/T, L/C, creditcard, PayPal, D/A, D/P, Western Union, MoneyGram

Levering vermogen

40.000 pc's per dag

Verwante Producten

Video

Polcd Small 2.8 inch 240x320 QVGA High Brightness 300nits MCU RGB interface IPS TFT display

Krijg Beste Prijs

Video

Polcd 2,8 inch TFT Display 240x320 Pixel IPS Screen Panel 37 Pin MCU ST7789V TFT LCD-module

Krijg Beste Prijs

Video

Polcd OEM 2.8" tft lcd 240x320 262K Kleuren ST7789V driver IC MCU 18-bit interface Aangepast LCD Scherm

Krijg Beste Prijs

Video

Polcd Kleine LCD 2.8' 240x320 Industrial IPS Kleur scherm Full View 2.8 inch Parallel Port TFT LCD Display

Krijg Beste Prijs

Contacteer ons

00-86-13714394335

anna@polcd.com

86-755-21011746

Contact nu

Productomschrijving

Description:

2.8 inch IPS TFT LCDs are commonly used in various electronic devices, including handheld gaming devices, industrial controllers, portable multimedia players, medical devices, and automotive displays, among others. Their compact size, high-quality display performance, and low power consumption make them a reliable and versatile display solution for various applications. The customizable display driver in some models also allows for greater flexibility and control over the display performance and features, making them suitable for a wide range of applications.

Parameter:

Model	P028B055-IPS
Screen Size	2.8 inch
Number of Pixel	240RGB(H)x320(V)
Display area	43.20(H)x57.60(V)mm
Pixel pitch	0.06(H)x0.18(V)mm
Pins	15 pins
Outline Dimension	50.00x69.20x2.30mm
Pixel arrangement	RGB Vertical Stripe
Display mode	Normally Black
Viewing Direction(eye)	ALL
Display Color	262K
Luminance(cd/m2)	300 nit
Contrast Ratio	800:1
Interface	4-wire SPI
Back-light	LED Side-light type
Drive IC	ST7789V
Operation Temperature	-20~70℃
Storage Temperature	-30~80℃

Polcd Small 2.8 inch 240x320 QVGA High Brightness 300nits MCU RGB interface IPS TFT display 0
